Series CLR micro pressure regulators
TREATMENT >
C_FLUID CONTROL CATALOGUE
>
2018
175
TREATMENT
Series CLR micro pressure regulators
Ports G1/4, G1/8
With banjo stem with or without relieving
Available with or without banjo in technopolymer
Series CLR micro pressure regulators
are available with G1/8 and G1/4
connections. A piston with or without
relieving and VS function (valve with fast
draining) has been incorporated into its
design.
The body is in brass, while the
connection fitting is in technopolymer
which guarantees maximum lightness.
They can be supplied with or without
banjo and can be console mounted.
With a threaded top part of the body both
direct mounting to a valve outlet (1/8 and
1/4 threads) and console mounting are
easily facilitated.
The pressure is precisely regulated
simply by turning the polymer knob with
a locking nut available to set the desired
output.
»
»
Extremely lightweight
»
»
Compact
»
»
In-line or console mounting
GENERAL DATA
Construction
piston
Materials
brass body, technopolymer banjo, stainless steel spring; NBR O-ring
Ports
G1/8 - G1/4
Weight
Kg 0,035
Mounting
in-line or panel mounting (in any position)
Operating temperature
-5°C ÷ 50°C (with the dew point of the fluid lower than 2°C at the min. working temperature)
Inlet pressure
2 ÷ 10 bar
Outlet pressure
0,5 ÷ 10 bar
Nominal flow
see graphs
Secondary pressure relieving standard (all regulators are provided with high relief flow VS function)
