www.camozzi.com.Series CFB solenoid valves
C_FLUID CONTROL CATALOGUE
2
84
>
2018
CONTROL >
CONTROL
CFB
SERIES
A
OPERATION:
A = indirect
B = direct with linked diaphragm
D = direct
1
NUMBER OF WAYS - POSITIONS:
1 = 2/2-way NO
2 = 2/2-way NC
3 = 3/2-way NC
3
CONNECTIONS:
1 = G1/8
2 = G1/4
3 = G3/8
4 = G1/2
5 = G3/4
6 = G1
7 = G1 1/4
8 = G1 1/2
9 = G2
L
NOMINAL DIAMETER:
A = 1,4 mm
B = 2 mm
C = 2,5 mm
D = 2,8 mm
F = 4 mm
G = 6 mm
J = 8 mm
L = 11,5 mm
M = 13 mm
N = 13,5 mm
P = 18 mm
R = 26 mm
T = 32 mm
X = 45 mm
Z = 50 mm
R
DIAPHRAGM MATERIAL:
R = NBR
W = FKM
E = EPDM (on demand)
1
BODY MATERIAL:
1 = brass
2 = alimentary anti-limestone nickel-plated brass for high temperatures (on demand)
3 = alimentary nickel-plated brass (on demand)
B7
SOLENOID DIMENSION:
B7 = 22 mm
B8 = 30 mm
B9 = 36 mm
E
SOLENOID VOLTAGE:
B = 24V AC 50 Hz
D = 110V AC 50/60 Hz
E = 230V AC 50/60 Hz
2 = 12V DC
3 = 24V DC
NOTE: for some directly operated 2/2 NO solenoid valves, the solenoid to be used is the B8*K type (see also the TABLE FOR THE COUPLING BETWEEN
SOLENOIDS AND VALVES on page 2/1.30.03).
CODING EXAMPLE
CFB -
A 1 3 L -
R 1 -
B7 E
