Series CFB stainless steel solenoid valves CONTROL > C_FLUID CONTROL CATALOGUE > 2018
91
CONTROL
CODING EXAMPLE
CFB SERIES
D OPERATION:
D = direct
2 NUMBER OF WAYS - POSITIONS:
2 = 2/2-way NC
3 = 3/2-way NC
1 CONNECTIONS:
1 = G1/8
2 = G1/4
3 = G3/8
4 = G1/2
A NOMINAL DIAMETER:
A = 1.5 mm
B = 2 mm
C = 2.5 mm
E = 3 mm
F = 4 mm
W SEALS MATERIAL:
W = FKM
E = EPDM (on demand)
X BODY MATERIAL:
X = stainless steel
B8 SOLENOID DIMENSION:
B8 = 30 mm
E SOLENOID VOLTAGE:
B = 24V AC 50 Hz
D = 110V AC 50/60 Hz
E = 230V AC 50/60 Hz
2 = 12V DC
3 = 24V DC
CFB - D 2 1 A - W X - B8 E
See solenoids and connectors for solenoids in the section 2/2.35.
Mod. B8 = mod.124-800
* = complete the code according to coding example
Mod. 24V AC 50 Hz 110V AC 50/60 Hz 220/230V AC 50/60 Hz 12V DC 24V DC
CFB-D21A-* B8B (15VA) B8D (15VA) B8E (15VA) B82 (19W) B83 (19W)
CFB-D21B-.* B8B (15VA) B8D (15VA) B8E (15VA) B82 (19W) B83 (19W)
CFB-D21C-* B8B (15VA) B8D (15VA) B8E (15VA) B82 (19W) B83 (19W)
CFB-D22B-* B8B (15VA) B8D (15VA) B8E (15VA) B82 (19W) B83 (19W)
CFB-D22C-* B8B (15VA) B8D (15VA) B8E (15VA) B82 (19W) B83 (19W)
CFB-D22E-* B8B (15VA) B8D (15VA) B8E (15VA) B82 (19W) B83 (19W)
CFB-D23E-* B8B (15VA) B8D (15VA) B8E (15VA) B82 (19W) B83 (19W)
CFB-D23F-* B8B (15VA) B8D (15VA) B8E (15VA) B82 (19W) B83 (19W)
CFB-D24E-* B8B (15VA) B8D (15VA) B8E (15VA) B82 (19W) B83 (19W)
CFB-D24F-* B8B (15VA) B8D (15VA) B8E (15VA) B82 (19W) B83 (19W)
CFB-D32A-* B8B (15VA) B8D (15VA) B8E (15VA) B82 (19W) B83 (19W)
CFB-D32B-* B8B (15VA) B8D (15VA) B8E (15VA) B82 (19W) B83 (19W)
CFB-D32C-* B8B (15VA) B8D (15VA) B8E (15VA) B82 (19W) B83 (19W)
CFB-D32E-* B8B (15VA) B8D (15VA) B8E (15VA) B82 (19W) B83 (19W)
TABLE FOR THE COUPLING BETWEEN SOLENOIDS AND VALVES
