Hydrochecks Mod. 43N-PTA-40 and 43N-PTV-40
DIMENSIONS (mm)
Mod.
Strokes (mm)
A+
B
C
L+
SW1
43
N-PTA-40
50
85
100
32
114
13
43
N-PTA-40
100
85
105
32
114
13
43
N-PTA-40
150-200
85
125
47
114
13
43
N-PTV-40
50
85
100
32
114
13
43
N-PTV-40
100
85
105
32
114
13
43
N-PTV-40
150-200
85
125
47
114
13
+ = add the stroke
Hydrochecks Mod. 43N-PTB-40
DIMENSIONS (mm)
Mod.
Strokes (mm)
A+
B
C
L+
SW1
43
N-PTB-40
50
85
100
32
114
13
43
N-PTB-40
100
85
105
32
114
13
43
N-PTB-40
150-200
85
125
47
114
13
+ = add the stroke
