Hydro-Checks & Shock-Absorbers
Hydro-Checks & Shock-Absorbers
6
NORTH AMERICAN CYLINDER & ACTUATOR CATALOG
>
Release 8.5
324
Hydrochecks Mod. 43N-PSB-40
DIMENSIONS (mm)
Mod.
Strokes (mm)
A+
B
C
L+
SW1
43
N-PSB-40
50
85
100
32
114
13
43
N-PSB-40
100
85
105
32
114
13
43
N-PSB-40
150-200
85
125
47
114
13
+ = add the stroke
Mounting kit Mod. 43N-40
Hydrocheck mounting kit for cylinders Ø 40 - 50 - 63 - 80.
DIMENSIONS (mm)
Mod.
A B C
D E F G H I
J
K
L
M N O P Q R S
43
N-40-40
60
-
110 26,5 56
-
12
7
19 47
M12X1,25 24 14
80
25 25 14 12 40
43
N-40-50
70
60 122 32,5 62 57 12
9
24 65
M16X1,5
32 20
88
32 25 14 14 40
43
N-40-63
80
60 132 37,5 67 57 20
9
24 65
M16X1,5
32 20
93
32 25 14 14 40
43
N-40-80
100 60 152 47,5 77 57 20 11 30 78
M20X1,5
40 25 107
-
-
-
18 50
