Shock Absorbers Series SA
DIMENSIONS (mm)
Mod.
A
B
C
D
E
F
G
I
L
SW
X
SA-0806W
M8X1
40,6
-
2,8
-
33,6
2
3
-
11
6
SA-0806
M8X1
40,6
6,6
2,8
8,5
33,6
2
3
55,2
11
6
SA-1007W
M10X1
47
-
3
-
39
3
3
-
12,7
7
SA-1007
M10X1
47
8,6
3
8,6
39
3
3
62,6
12,7
7
SA-1210W
M12X1
50
-
3
-
45,5
-
4
-
14
10
SA-1210
M12X1
50
10,3
3
8,5
45,5
-
4
68,5
14
10
SA-1412W
M14X1,5
67
-
4
-
58
4
6
-
19
12
SA-1412
M14X1,5
67
12
4
11
58
4
6
90
19
12
SA-2015W
M20X1,5
73
-
6
-
62
4
8
-
26
15
SA-2015
M20X1,5
73
18
6
15
62
4
8
103
26
15
SA-2525W
M25X1,5
92
-
8
-
82
-
10
-
32
25
SA-2525
M25X1,5
92
22
8
19
82
-
10
136
32
25
SA-2725W
M27X1,5
99
-
8
-
86
5
6,5
-
32
25
SA-2725
M27X1,5
99
22
8
19
86
5
6,5
143
32
25
