Proximity Switches
Proximity Switches
7
NORTH AMERICAN CYLINDER & ACTUATOR CATALOG
>
Release 8.5
342
Sensors Series CSV
CST sensors must be assembled
directly into the groove:
for cylinders ø16-25 Series 50
for cylinders ø12-16 Series QP-
QPR.
Sensors Series CST - CSH
CST/CSH sensors can be directly
mounted on the following cylinders:
Series 31 - 31R
Series 32 - 32R
Series 52
Series 61
Series 62 (CSH only)
Series 69
Series QC - QCBF - QCTF
Slot cover profile Mod. S-CST-500
Supplied in unit lengths of 500mm ea.
Mod.
S-CST-500
Slot cover profile for cylinders Series:
31 & 31
tandem and multi-position
-
QCT - QCB - QCBT-QCBF - 61 - 69 -
32 & 32
tandem and multi-position.
