Magnetic proximity switches with 2-wire or 3-wire cable Series CSH
For max. operating current see load curves diagrams.
Mod.
Operation
Voltage (V)
Output
Max current
Protection
CSH-223-2
Reed
10-30
AC/DC
-
250
mA
Against polarity reversing
CSH-223-5
Reed
10-30
AC/DC
-
250
mA
Against polarity reversing
CSH-221-2
Reed
30-230
AC
30-110
DC
-
250
mA
Against polarity reversing
CSH-221-5
Reed
30-230
AC
30-110
DC
-
250
mA
Against polarity reversing
CSH-233-2
Reed
10-30
AC/DC
PNP
250
mA
Against polarity reversing
CSH-233-5
Reed
10-30
AC/DC
PNP
250
mA
Against polarity reversing
CSH-334-2
Electronic
10-27
AC/DC
PNP
250
mA
Against polarity reversing and overvoltage
CSH-334-5
Electronic
10-27
AC/DC
PNP
250
mA
Against polarity reversing and overvoltage
In case of polarity reversing
the sensor will still be
operating, but the LED
diode won’t turn on.
Magnetic proximity switches with male connector M8 Series CSH
For max. operating current see load curves diagrams.
Mod.
Operation
Voltage (V)
Output
Max current
Max Load
Protection
CSH-253
Reed
10-30
AC/DC
-
250
mA
Against polarity reversing
CSH-263
Reed
10-30
AC/DC
PNP
250
mA
Against polarity reversing
CSH-364
Electronic
10-27
AC/DC
PNP
250
mA
Against polarity reversing and overvoltage
In case of polarity reversing
the sensor will still be
operating, but LED diode
won’t turn on.
