CODING EXAMPLE
K8DV SERIES
C TYPE OF BODY:
C = cartridge version
0 = flanged version
00 NUMBER OF POSITIONS:
00 = valve without housing
5 NUMBER OF WAYS - FUNCTIONS:
5 = 2-way NC
0 SEAL MATERIAL:
0 = FKM
4 = EPDM
5 NOMINAL DIAMETER:
5 = Ø 0.7 mm
G BODY MATERIAL:
G = PEEK
2 ELECTRICAL CONNECTION:
2 = interface pin size 4 mm
3 VOLTAGE - POWER CONSUMPTION:
1 = 6V DC - 0.6 W
2 = 12V DC - 0.6 W
3 = 24V DC - 0.6 W
4 = 3V DC - 0.6 W
5 = 5V DC - 0.6 W
K8DV C 00 - 5 0 5 - G 2 3
