Series K8DV solenoid valves
CONTROL >
C_FLUID CONTROL CATALOGUE
>
2018
23
CONTROL
Solenoid valve with fluid separation membrane, cartridge version
Mod.
Nominal diameter Ø (mm)
kv (l/min)
Min÷max pressure (bar)
Body material
Seal material
K8DVC00-505-G2*
0.7
0.1
0 ÷ 2.1
PEEK
FKM
K8DVC00-545-G2*
0.7
0.1
0 ÷ 2.1
PEEK
EPDM
DRAWING LEGEND:
1 = supply
2 = inlet
NOTE TO THE TABLE:
* to complete the code add
VOLTAGE - POWER
CONSUMPTION(see the
CODING EXAMPLE)
Solenoid valve seat, cartridge version
DRAWING LEGEND:
1 = supply
2 = inlet
