www.camozzi.com.Series K8DV solenoid valves
C_FLUID CONTROL CATALOGUE
2
24
>
2018
CONTROL >
CONTROL
Solenoid valve with fluid separation membrane, flanged version
Mod.
Nominal diameter Ø (mm)
kv (l/min)
Min÷max pressure (bar)
Body material
Seal material
K8DV000-505-G2*
0.7
0.1
0 ÷ 2.1
PEEK
FKM
K8DV000-545-G2*
0.7
0.1
0 ÷ 2.1
PEEK
EPDM
DRAWING LEGEND:
1 = supply
2 = inlet
NOTE TO THE TABLE:
* to complete the code add
VOLTAGE - POWER
CONSUMPTION (see the
CODING EXAMPLE)
Mounting pad of the flanged solenoid valve
DRAWING LEGEND:
1 = supply
2 = inlet
