31 / 220
General terms and conditions for sale are available on
www.camozzi.com.Series K solenoid valves
C_FLUID CONTROL CATALOGUE
2
28
>
2018
CONTROL >
CONTROL
2/2-way NC solenoid valve (90° electrical connection)
Supplied with:
1x interface seal
2x screws M1.6x16
(UNI 10227 for mounting on plastics or
UNI 7687 for mounting on metal)
Mod.
Function Orifice Ø (mm)
kv (l/min)
Qn (Nl/min)
Min÷max pressure (bar)
K000-102-F1*
2/2 NC
0.6
0.15
10
0 ÷ 7
K000-102-F2*
2/2 NC
0.6
0.15
10
0 ÷ 7
K000-102-F3*
2/2 NC
0.6
0.15
10
0 ÷ 7
K000-105-F1*
2/2 NC
1
0.30
-
0 ÷ 3
K000-105-F2*
2/2 NC
1
0.30
-
0 ÷ 3
K000-105-F3*
2/2 NC
1
0.30
-
0 ÷ 3
* add VOLTAGE - POWER
CONSUMPTION (see CODING
EXAMPLE)
2/2-way NC solenoid valve (in-line electrical connection)
Supplied with:
1x interface seal
2x screws M1.6x16
(UNI 10227 for mounting on plastics or
UNI 7687 for mounting on metal)
Mod.
Function Orifice Ø (mm)
kv (l/min)
Qn (Nl/min) Min÷max pressure (bar)
K000-102-FB*
2/2 NC
0.6
0.15
10
0 ÷ 7
K000-102-FC*
2/2 NC
0.6
0.15
10
0 ÷ 7
K000-102-FD*
2/2 NC
0.6
0.15
10
0 ÷ 7
K000-105-FB*
2/2 NC
1
0.30
-
0 ÷ 3
K000-105-FC*
2/2 NC
1
0.30
-
0 ÷ 3
K000-105-FD*
2/2 NC
1
0.30
-
0 ÷ 3
* add VOLTAGE - POWER
CONSUMPTION (see CODING
EXAMPLE)
2/2-way NC solenoid valve (with cable 300 mm)
Supplied with:
1x interface seal
2x screws M1.6x16
(UNI 10227 for mounting on plastics or
UNI 7687 for mounting on metal)
Mod.
Function Orifice Ø (mm)
kv (l/min)
Qn (Nl/min) Min÷max pressure (bar)
K000-102-FF*
2/2 NC
0.6
0.15
10
0 ÷ 7
K000-102-FG*
2/2 NC
0.6
0.15
10
0 ÷ 7
K000-102-FH*
2/2 NC
0.6
0.15
10
0 ÷ 7
K000-105-FF*
2/2 NC
1
0.30
-
0 ÷ 3
K000-105-FG*
2/2 NC
1
0.30
-
0 ÷ 3
K000-105-FH*
2/2 NC
1
0.30
-
0 ÷ 3
* add VOLTAGE - POWER
CONSUMPTION (see CODING
EXAMPLE)
