Series K solenoid valves
CONTROL >
C_FLUID CONTROL CATALOGUE
>
2018
29
CONTROL
3/2-way NC solenoid valve (90° electrical connection)
Supplied with:
1x interface seal
2x screws M1.6x16
(UNI 10227 for mounting on plastics or
UNI 7687 for mounting on metal)
Mod.
Function Orifice Ø (mm)
kv (l/min)
Qn (Nl/min) Min÷max pressure (bar)
K000-303-K1*
3/2 NC
0.6
0.12
8
0 ÷ 7
K000-303-F1*
3/2 NC
0.6
0.12
8
0 ÷ 7
K000-303-K2*
3/2 NC
0.6
0.12
8
0 ÷ 7
K000-303-F2*
3/2 NC
0.6
0.12
8
0 ÷ 7
K000-303-K3*
3/2 NC
0.6
0.12
8
0 ÷ 7
K000-303-F3*
3/2 NC
0.6
0.12
8
0 ÷ 7
* add VOLTAGE - POWER
CONSUMPTION (see CODING
EXAMPLE)
3/2-way NC solenoid valve (in-line electrical connection)
Supplied with:
1x interface seal
2x screws M1.6x16
(UNI 10227 for mounting on plastics or
UNI 7687 for mounting on metal)
Mod.
Function Orifice Ø (mm)
kv (l/min)
Qn (Nl/min) Min÷max pressure (bar)
K000-303-KB*
3/2 NC
0.6
0.12
8
0 ÷ 7
K000-303-FB*
3/2 NC
0.6
0.12
8
0 ÷ 7
K000-303-KC*
3/2 NC
0.6
0.12
8
0 ÷ 7
K000-303-FC*
3/2 NC
0.6
0.12
8
0 ÷ 7
K000-303-KD*
3/2 NC
0.6
0.12
8
0 ÷ 7
K000-303-FD*
3/2 NC
0.6
0.12
8
0 ÷ 7
* add VOLTAGE - POWER
CONSUMPTION (see CODING
EXAMPLE)
3/2-way NC solenoid valve (with cable 300 mm)
Supplied with:
1x interface seal
2x screws M1.6x16
(UNI 10227 for mounting on plastics or
UNI 7687 for mounting on metal)
Mod.
Function Orifice Ø (mm)
kv (l/min)
Qn (Nl/min) Min÷max pressure (bar)
K000-303-KF*
3/2 NC
0.6
0.12
8
0 ÷ 7
K000-303-FF*
3/2 NC
0.6
0.12
8
0 ÷ 7
K000-303-KG*
3/2 NC
0.6
0.12
8
0 ÷ 7
K000-303-FG*
3/2 NC
0.6
0.12
8
0 ÷ 7
K000-303-KH*
3/2 NC
0.6
0.12
8
0 ÷ 7
K000-303-FH*
3/2 NC
0.6
0.12
8
0 ÷ 7
* add VOLTAGE - POWER
CONSUMPTION (see CODING
EXAMPLE)
