www.camozzi.com.Series K solenoid valves
C_FLUID CONTROL CATALOGUE
2
30
>
2018
CONTROL >
CONTROL
3/2-way NO solenoid valve (90° electrical connection)
Supplied with:
1x interface for NO version
(connections 1 and 3 are inverted)
2x interface seals for NO version
2x screws M1.6x19
(UNI 10227 for mounting on plastics or
UNI 7687 for mounting on metal)
If no interface is needed, use screws M1.6x16 Mod.
K303/61 for plastics or K303/61M for metal.
Mod.
Function Orifice Ø (mm)
kv (l/min)
Qn (Nl/min) Min÷max pressure (bar)
K000-403-K1*
3/2 NO
0.8
0.20
-
0 ÷ 5
K000-403-F1*
3/2 NO
0.8
0.20
-
0 ÷ 5
K000-403-K2*
3/2 NO
0.8
0.20
-
0 ÷ 5
K000-403-F2*
3/2 NO
0.8
0.20
-
0 ÷ 5
K000-403-K3*
3/2 NO
0.8
0.20
-
0 ÷ 5
K000-403-F3*
3/2 NO
0.8
0.20
-
0 ÷ 5
* add VOLTAGE - POWER
CONSUMPTION (see CODING
EXAMPLE)
3/2-way NO solenoid valve (in-line electrical connection)
Supplied with:
1x interface for NO version
(connections 1 and 3 are inverted)
2x interface seals for NO version
2x screws M1.6x19
(UNI 10227 for mounting on plastics or
UNI 7687 for mounting on metal)
If no interface is needed, use screws M1.6x16 Mod.
K303/61 for plastics or K303/61M for metal.
Mod.
Function Orifice Ø (mm)
kv (l/min)
Qn (Nl/min) Min÷max pressure (bar)
K000-403-KB*
3/2 NO
0.8
0.20
-
0 ÷ 5
K000-403-FB*
3/2 NO
0.8
0.20
-
0 ÷ 5
K000-403-KC*
3/2 NO
0.8
0.20
-
0 ÷ 5
K000-403-FC*
3/2 NO
0.8
0.20
-
0 ÷ 5
K000-403-KD*
3/2 NO
0.8
0.20
-
0 ÷ 5
K000-403-FD*
3/2 NO
0.8
0.20
-
0 ÷ 5
* add VOLTAGE - POWER
CONSUMPTION (see CODING
EXAMPLE)
3/2-way NO solenoid valve (with cable 300 mm)
Supplied with:
1x interface for NO version
(connections 1 and 3 are inverted)
2x interface seals for NO version
2x screws M1.6x19
(UNI 10227 for mounting on plastics or
UNI 7687 for mounting on metal)
If no interface is needed, use screws M1.6x16 Mod.
K303/61 for plastics or K303/61M for metal.
Mod.
Function Orifice Ø (mm)
kv (l/min)
Qn (Nl/min) Min÷max pressure (bar)
K000-403-KF*
3/2 NO
0.8
0.20
-
0 ÷ 5
K000-403-FF*
3/2 NO
0.8
0.20
-
0 ÷ 5
K000-403-KG*
3/2 NO
0.8
0.20
-
0 ÷ 5
K000-403-FG*
3/2 NO
0.8
0.20
-
0 ÷ 5
K000-403-KH*
3/2 NO
0.8
0.20
-
0 ÷ 5
K000-403-FH*
3/2 NO
0.8
0.20
-
0 ÷ 5
* add VOLTAGE - POWER
CONSUMPTION (see CODING
EXAMPLE)
