38 / 220
General terms and conditions for sale are available on
www.camozzi.com.2
Series KN and KN High Flow solenoid valves
CONTROL >
C_FLUID CONTROL CATALOGUE
>
2018
35
CONTROL
3/2-way solenoid valve - in-line electrical connection
Supplied with:
1x interface seal
2x screws M1.6x16 UNI 10227
(fixing for plastics, standard)
or
2x screws M1.6x16 UNI 7687
(fixing for metal, M option)
Mod.
Function Orifice Ø
(mm)
kv
(l/min)
Qn
(Nl/min)
Min÷max
pressure (bar)
Power
consumption (W)
Symb.
KN000-303-KB* 3/2 NC 0.65 0.15
10
0 ÷ 7
1.3 / 0.25
EV04
KN000-303-FB* 3/2 NC 0.65 0.15
10
0 ÷ 7
1.3 / 0.25
EV04
KN000-305-FB* 3/2 NC 1.1 0.39
25
3 ÷ 7
4 / 1
EV04
KN000-306-FB* 3/2 NC 1.1 0.39
-
0 ÷ 3
4 / 1
EV04
KN000-403-FB* 3/2 NO 0.65 0.15
10
0 ÷ 7
1.3 / 0.25
EV05
KN000-706-FB* 3/2 UNI
1.1 0.39
-
0 ÷ 1.5
4 / 1
EV64
* add VOLTAGE - POWER
CONSUMPTION (see CODING
EXAMPLE)
Single sub-base
Note: use solenoid valves with mounting screws on
metal interfaces (see codification).
Mod.
KN01-02
Connector Mod. 121-8..
Mod.
description
colour
L = cable length (mm)
cable holding
121-803
crimped cable
black
300
crimping
121-806
crimped cable
black
600
crimping
121-810
crimped cable
black
1000
crimping
121-830
crimped cable
black
3000
crimping
