Series W solenoid valves
CONTROL >
C_FLUID CONTROL CATALOGUE
>
2018
41
CONTROL
Double sided manifold with rear outlets
DIMENSIONS
Mod.
Nr valves
L
L1
L2
L3
1 (P)
3 (R)
P204-0*
4
53
39
18,5
16
G1/8
G1/8
P206-0*
6
69
55
18,5
16
G1/8
G1/8
P208-0*
8
85
71
18,5
16
G1/8
G1/8
P210-0*
10
101
87
18,5
16
G1/8
G1/8
P212-0*
12
117
103
18,5
16
G1/8
G1/8
* = see the type of PORTS in the
CODING EXAMPLE TABLE.
A = groove for electric connection
identification
Double sided manifold with front outlets
This manifold is arranged to be fixed through
DIN 46277/3 guide together with the accessory
PCF-E520.
DIMENSIONS
Mod.
Nr valves
L
LI
L2
L3
1 (P)
3 (R)
P204-0*
4
53
39
18,5
16
G1/8
G1/8
P206-0*
6
69
55
18,5
16
G1/8
G1/8
P208-0*
8
85
71
18,5
16
G1/8
G1/8
P210-0*
10
101
87
18,5
16
G1/8
G1/8
P212-0*
12
117
103
18,5
16
G1/8
G1/8
* = see the type of PORTS in the
CODING EXAMPLE TABLE.
A = groove for electric connection
identification
Connector Mod. 126-... DIN EN 175 301-803-C (8 mm)
To be used in all DC valves with voltages from 6 to
110 V.
Mod.
description
colour
working
voltage
cable length
[ L ]
cable
holding
tightening
torque
126-550-1 moulded cable,
without electronics
black
-
1000 mm -
0.3 Nm
126-800 connector, without
electronics
black
-
-
PG7
0.3 Nm
126-701 connector, varistor
+ Led
transparent
24 V AC/
DC
-
PG7
0.3 Nm
1 = 90° adjustable connector
