Series W solenoid valves
CONTROL >
C_FLUID CONTROL CATALOGUE
>
2018
39
CONTROL
3/2-way NC solenoid valve, DIN EN 175 301-803-C (8 mm)
Supplied with:
1x interface seal
2x screws M3x20 UNI 8112
(fixing for metal, standard)
or
2x screws M3x23 UNI 10227
(fixing for plastics, P option)
Mod.
Orifice Ø (mm)
kv (l/min)
Qn (Nl/min)
Pressure min-max (bar)
W000-305-W23
1.1
0.39
25
0 ÷ 10
W000-303-W23
1.5
0.54
35
0 ÷ 7
W000-305-W24
1.1
0.39
25
0 ÷ 10
W000-303-W24
1.5
0.54
35
0 ÷ 7
3/2-way NO solenoid valve, DIN EN 175 301-803-C (8 mm)
Supplied with:
1x interface for NO version
(connections 1 and 3 are inverted)
2x interface seals
2x screws M3x25 UNI 8112 (for standard version)
Mod.
Orifice Ø (mm)
kv (l/min)
Qn (Nl/min)
Pressure min-max (bar)
W000-405-W23
0.9
0.23
15
0 ÷ 10
W000-403-W23
1.5
0.39
-
0 ÷ 5
W000-405-W24
0.9
0.23
15
0 ÷ 10
W000-403-W24
1.5
0.39
-
0 ÷ 5
3/2-way NC solenoid valve with cables of 300mm
Supplied with:
1x interface seal
2x screws M3x20 UNI 8112
(fixing for metal, standard)
or
2x screws M3x23 UNI 10227
(fixing for plastics, P option)
Mod.
Orifice Ø (mm)
kv (l/min)
Qn (Nl/min)
Pressure min-max (bar)
W000-305-W13
1.1
0.39
25
0 ÷ 10
W000-303-W13
1.5
0.54
35
0 ÷ 7
