www.camozzi.com.Series W solenoid valves
C_FLUID CONTROL CATALOGUE
2
38
>
2018
CONTROL >
CONTROL
CODING EXAMPLE
W
SERIES
0
BODY DESIGN:
0 = single sub-base (only M5) or interface
1 = single manifold
2 = double manifold
00
NUMBER OF POSITIONS:
00 = interface
01 = single base (M5 only)
02 ÷ 99 = manifold number of positions
3
NUMBER OF WAYS - FUNCTIONS:
0 = manifold or single sub-base
3 = 3-way NC
4 = 3-way NO
5 = 3-way NC electric part revolved by 180°
6 = 3-way NO electric part revolved by 180°
0
VALVE PORTS:
0 = interface
MANIFOLD PORTS (for Series W, P and PN):
2 = M5 side
3 = tube ø 3 side
4 = tube ø 4 side
6 = M5 rear ports
7 = ø 3 tube rear ports
8 = ø 4 tube rear ports
3
NOMINAL DIAMETER - MAX PRESSURE
1 = ø 0,8 (1W) 10 bar (NC) 24V only
3 = ø 1,5 (2W) 7 bar (NC) 5 bar (NO)
5 = ø 1,1 NC (2W) 10 bar (NC)
ø 0,9 NO (2W) 10 bar (NO)
W
MATERIALS:
W = technopolymer PBT body, FKM poppet seal, other seals in NBR (FKM on demand)
2
ELECTRICAL CONNECTION:
1 = cables (L = 300 mm)
2 = DIN EN 175 301-803-C (8 mm)
3
SOLENOID VOLTAGE:
2 = 12V DC
3 = 24V DC
4 = 48V DC
FIXING:
= with screws for metal (standard)
P = with screws for plastics
W 0 00 -
3 0 3 -
W 2 3
