Circuits with dual commands

In some situations itmay be useful to have a second command in addition to the cycle start command, onewhich

permitsmaintenance or adjustment of the individual actuators once the sequence has stopped.

Figure 18

Pos. 1: Controlling a double-acting cylinder withBistable 5/2-way solenoid valve

.

Line 1:

when the

C.C.

(Continuous Cycle) button is pressed, the output signal reaches the closed End Cycle

F.C.

,

button. It passes through, arriving at, and energizing the coil of relay

X

. Contact

x

of this relay, connected in

parallel with the

C.C.

button, closes and latches the

C.C.

buttonwhich can now be released.

Line 2:

also contact

x

on this line closes and the signal reaches limit switch

a0

which by detecting the position

of the piston rod/piston at the negative end position, permits the signal to pass and energize solenoid

B1

of the

solenoid valve. The solenoid valve changes over and the piston rod/piston executes the positive stroke, reaching

position

a1

.With the release of the limit switch in position

a0

the contact opens and interrupts the passage of the

signal to solenoid

B1

. Even in the absence of this command, the bistable solenoid valve maintains the position

given by the last received signal.

Line3:

Onceposition

a1

has been reached, the corresponding limit switch is activated thereby closing the contact,

allowing the signal to energize solenoid

B2

. The solenoid valve changes over and the piston rod/piston executes

the negative stroke.

Once the position has been reached, limit switch

a0

re-activates, the signal is then free to pass (as the contact

X

is still closed), re-energizing solenoid

B1

, and the sequence repeats.With the release of switch limit

a1

, the signal

to solenoid

B2

is interrupted.

By pressing the EndCycle

F.C.

button, relay

X

de-energizes and opens contact

x

on

Line1

releasing the latch, the

cylinder can only be restarted if the

C.C.

button is pressed again.

Pressing the Single Cycle

C.S.

(

Line 2

) while the piston rod/piston is at end position

a0

causes solenoid

B1

to

energize.

The solenoid valve changes over, the piston rod/piston completes the positive stroke. Upon reaching limit switch

a1

, if the

C.S.

button is released, solenoid

B2

is energized to execute the negative stroke. Once the negative end

position has been reached, the cylinder stops.

In the event of a power failure the piston rod/pistonwould complete the current stroke and then stop. If it were in

the positive end positionwhen the power is restored, it would return immediately to its starting position as signal

a1

energizes solenoid

B2

.

Note

: The

C.S.

button can not be placed in parallel with contact

x

on

Line 1

and the

C.C.

button, as its activation

would drive the coil of the relay

X

, to energize, cancelling the single cycle function. (Ref. circuit in the box).

Figure 18

Pos. 2: Control of a double-acting cylinder with aMonostable 5/2-way solenoid valve

.

With this type of solenoid valve the

C.C.

and

C.S.

commands must be memorized for the duration of the positive

stroke.

Line 1:

by pushing and holding down the

C.C.

button, the signal reaches and passes through the contact of the

F.C.

buttonand energizes the coil of relay

X

thereby closing contact

x

. This contact, inparallel with the

C.C.

button

latches. The

C.C.

button can then be released.

Line 2:

also contact

x

on this line closes, the signal passes and reaches limit switch

a0

, which, by detecting the

position of the piston rod/piston at the negative end position, allows the signal to energize solenoid

B1

, the signal

also reaches the coil of relay

Y

on

Line 3

.

Line 3:

when the coil of relay

Y

energizes, its respective contact

y

closes. As contact

z

is closed, the signal once

again reaches the coil of relay

Y

and latches.

Line 4:

with solenoid

B1

on

Line 2

energized, the piston rod/piston initiates its movement towards limit switch

a1

, which, once reached, allows the signal to reach the coil of relay

Z

.

When contact

z

opens, the coil of relay

Y

is de-energized. Opening contact

y

and releasing the latch interrupts the

energizing of solenoid

B1

. The solenoid valve, due to the effect of the internal spring, returns to its rest position and

the piston rod/piston completes thenegative stroke.With the activation of the limit switch

a0

, the signal, still active

on

Line 2

, will once again reach solenoid

B1

and the coil of relay

Y

, and a new sequence begins.

By pressing the

F.C.

button, the coil of relay

X

de-energizes, the contact

x

on

Line 2

opens and interrupts the

energizing of solenoid

B1

and the coil of relay

Y

.

TheSingleCyclebutton

C.S.

(

Line2

) is inparallel with contact

x

and repeats the flow illustratedaboveby stopping

the cycle when the piston rod/piston reaches the negative end position again. For a new Single Cycle the

C.S.

buttonmust be pressed.

In the event of a power failure, the cylinder immediately returns to the start position. The restart is obtained by

pressing the

C.S.

or

C.C.

buttons.
