NORTH AMERICAN CYLINDER & ACTUATOR CATALOG
>
Release 8.5
The company reserves the right to vary models and dimensions without notice.
These products are designed for industrial applications and are not suitable for sale to the general public.
ISO / VDMA CYLINDERS
ISO / VDMA Cylinders
1
21
Front female trunnion Mod. H and C-H
Material: Aluminium
DIMENSIONS (mm)
Mod.
CB
UB
E
XD+
FL
L
CD
MR
torque force
H-41-32
26
45
45
120
22
12
10
10
6
Nm
H-41-40
28
52
52
135
25
15
12
13
6
Nm
H-41-50
32
60
63
143
27
15
12
13
13
Nm
H-60-63
40
70
73
158
32
20
16
15
13
Nm
C-H-41-80
50
90
95
174
36
24
16
15
19
Nm
C-H-41-100
60
110
115
189
41
29
20
18
22
Nm
C-H-41-125
70
130
135
225
50
30
25
25
22
Nm
Supplied with:
1
x trunnion
4
x screws
+ = add the stroke
Rear male trunnion Mod. L
Material: Aluminium
DIMENSIONS (mm)
Mod.
Ø
CD
L
FL
XD+
MR
E
EW
torque force
L-41-32
32
10
12
22
142
9
45
26
6
Nm
L-41-40
40
12
15
25
160
13
52
28
6
Nm
L-41-50
50
12
15
27
170
13
63
32
13
Nm
L-41-63
63
16
20
32
190
15
73
40
13
Nm
L-41-80
80
16
24
36
210
15
95
50
19
Nm
L-41-100
100
20
29
41
230
18
115
60
22
Nm
L-41-125
125
25
30
50
275
25
135
70
26
Nm
Supplied with:
1
x male trunnion
4
x screws
+ = add the stroke
EXPRESS DELIVERY AVAILABLE
