ISO / VDMA CYLINDERS
ISO / VDMA Cylinders
1
20
Front and rear flange Mod. D-E
Material: Aluminium
DIMENSIONS (mm)
Mod.
Ø
W
MF
ZB
TF
R
UF
E
FB
ZF
torque force
D-E-41-32
32
16
10
120
64
32
86
45
7
130
6
Nm
D-E-41-40
40
20
10
135
72
36
88
52
9
145
6
Nm
D-E-41-50
50
25
12
143
90
45
110
63
9
155
13
Nm
D-E-41-63
63
25
12
158
100
50
116
73
9
170
13
Nm
D-E-41-80
80
30
16
174
126
63
148
95
12
190
19
Nm
D-E-41-100
100
35
16
189
150
75
176
115
14
205
22
Nm
D-E-41-125
125
45
20
225
180
90
224
135
16
245
26
Nm
Supplied with:
1
x flange
4
x screws
+ = add the stroke
Rear female trunnion Mod. C and C-H
Material: Aluminium
DIMENSIONS (mm)
Mod.
Ø
CD
L
FL
XD+
MR
E
CB
UB
torque force
C-41-32
32
10
12
22
142
10
45
26
45
6
Nm
C-41-40
40
12
15
25
160
13
52
28
52
6
Nm
C-41-50
50
12
15
27
170
13
63
32
60
13
Nm
C-H-41-63
63
16
20
32
190
15
73
40
70
13
Nm
C-H-41-80
80
16
24
36
210
15
95
50
90
19
Nm
C-H-41-100
100
20
29
41
230
18
115
60
110
22
Nm
C-H-41-125
125
25
30
50
275
25
135
70
130
26
Nm
Supplied with:
1
x female trunnion
4
x screws
+ = add the stroke
