Fittings Mod. 6708...
"
Hybrid" Torque Specifications - ( Sprint - BSP Fittings assembled into female NPTF ports)
Fittings Mod. 6555...
DIMENSIONS
OD
mm
Mod.
A
F
L
6708 4
* 4
mm or 5/32"
10.7 10.7
6708 5
5
11.7 11
6708 6
* 6
mm or 1/4"
13.7 11.5
6708 8
* 8
mm or 5/16"
15.7 12.5
6708 10
* 10
mm or 3/8"
18.5 13
6708 12
* 12
mm or 1/2"
20.7 15
6708 12
* 12
mm or 1/2"
23.7 15
Thread Size
Minimum Torque Value
Maximum Torque Value
Sprint
Nm
Ft-Lbs
Nm Ft-Lbs
1/8" *
1.0
0.7
10.0
7.4
1/4" *
4.0
2.9
20.0
14.8
3/8"
27.0
20.0
54.0
40.0
1/2"
27.0
20.0
67.0
50.0
DIMENSIONS
OD
mm
OD
mm
Mod.
A G C L
F
T
M SW
6555 4-4
4
4 3.5 22 9 16.5 17.5
8
6555 6-6
6
6 4 24.5 12.7 18 20
9
6555 8-8
8
8 5 27.5 14.2 20 22.5
11
6555 10-10
10 10 5.8 32 16.5 23 26
13
Self-extinguishing material black color, class VO
Dust Cap
Caution
:
Mating material and female ports may be too soft for high torque values.
Check material hardness to avoid stripping, galling or cross-threading.
This table is ONLY a guide for "hybrid" situations that require interchanging thread types to accommodate tubing requirements.
* -
NOTE: Value is the same as standard value for equal thread types, ( BSP to BSP)
Stem Elbow
B S P / M E T R I C
The company reserves the right to vary models and dimensions without notice.
These products are designed for industrial applications and are not suitable for sale to the general public.
