Fittings Mod. 6811...
Fittings Mod. 6850...
Fittings Mod. 6950...
DIMENSIONS
OD
mm
Mod.
G D H T
L
SW
*6811-4-
M5
4
M5
4
16.5 24.5
8
*
6811-4-1/8
4
G1/8 5.5 16.5 27.8
12
*
6811 5-1/8
5
G1/8 5.5
18
29.3
12
*
6811 5-1/4
5
G1/4 7
18
31
14
*
6811 6-1/8
6
G1/8 5.5
18
29.3
12
*
6811 6-1/4
6
G1/4 7
18
31
14
*
6811 8-1/8
8
G1/8 5.5 20.5 31.8
12
*
6811 8-1/4
8
G1/4 7
20.5 33.5
14
*
6811 10-1/4
10
G1/4 7
23
36
14
*
6811 10-3/8
10
G3/8 8
23
37.3
19
*
6811 12-3/8
12
G3/8 8
24
38.3
19
*
6811 14-3/8
14
G3/8 8
28
42.3
19
*
6811 14-1/2
14
G1/2 9
28
44
22
DIMENSIONS
OD
mm
Mod.
G L
6950 4
4 32.5
6950 6
6 35.5
6950 8
8 40.5
6950 10
10 46
6950 12
12 48
6950 14
14 52
DIMENSIONS
OD
mm
OD
mm
Mod.
A
G C
F
L
T
6850 6-4
6
4 17.5 12.7
33.5
16.5
6850 8-6
8
6
19
14
36.5
18
Sprint
®
Stem Adapter
*
with O-ring assembled
Double Union
Expander
B S P / M E T R I C
The company reserves the right to vary models and dimensions without notice.
These products are designed for industrial applications and are not suitable for sale to the general public.
62
F I T T I N G S
2
n i c k e l - p l a t e d b r a s s p ush - i n F I T T I NGS
