COMPACT AND SHORT-STROKE CYLINDERS
Compact and Short-Stroke Cylinders
2
NORTH AMERICAN CYLINDER & ACTUATOR CATALOG
>
Release 8.5
114
Foot mount Mod. B
Material: zinc-plated steel
DIMENSIONS (mm)
Mod.
Ø
C
SA+
XA+
TR
ØAB
AH
AO
AC
B-31-12-16
12 - 16
3
64
51
18
5,5
22
7
20
B-32-20
20
4
70
54
22
6,6
27
9
25
B-31-25
25
4
71,5
55,5
26
6,6
29
9
25
B-31-32
32
5
80,5
62,5
32
6,6
34
12
30
B-31-40
40
5
85,5
65,5
42
9
40,5
10
30
B-31-50
50
5,5
93,5
69,5
50
9
47
11
35
B-31-63
63
5,5
104
77
62
11
56,5
13
40
B-31-80
80
7,5
116
86
82
11
68,5
15
45
B-31-100
100
7,5
132,5
99,5
103
13,5
81
12
45
Supplied with:
2
x feet
4
x screws
+ = add the stroke
Rear and front flange Mod. D-E
Material: zinc-plated steel
DIMENSIONS (mm)
Mod.
Ø
C
ZB+
TF
R
UF
G1
ØFB
D-E-31-12-16
12 - 16
10
48
43
-
55
29
5,5
D-E-32-20
20
10
48
55
-
70
36
6,6
D-E-32-25
25
10
49,5
60
-
76
40
6,6
D-E-31-32
32
10
54,5
65
32
80
50
7
D-E-31-40
40
10
55,5
82
36
102
60
9
D-E-31-50
50
12
57,5
90
45
110
68
9
D-E-31-63
63
15
65
110
50
130
87
9
D-E-31-80
80
15
71
135
63
160
107
12
D-E-31-100
100
15
81,5
163
75
190
128
14
Supplied with:
1
x flange
4
x screws
+ = add the stroke
