Compact and Short-Stroke Cylinders
2
NORTH AMERICAN CYLINDER & ACTUATOR CATALOG
>
Release 8.5
COMPACT AND SHORT-STROKE CYLINDERS
115
Female rear trunnion Mod. C
Material: Aluminium
DIMENSIONS (mm)
Mod.
Ø
ØCD
L
C
XD+
MR
F
G
CB
UB
HB
C-31-32
32
10
13
21
66,5
11
32
50
26
45
54
C-31-40
40
12
16
25
70,5
13
42
60
28
52
62
C-31-50
50
12
16
27
72,5
13
50
68
32
60
70
C-31-63
63
16
21
32
82
17
62
87
40
70
82
C-31-80
80
16
23
36
92
17
82
102
50
90
102
C-31-100
100
20
26
41
107,5
21
103
128
60
110
126
Supplied with:
4
x screws
1
x clevis pin
1
x centering pin
1
x trunnion
+ = add the stroke
Intermediate bracket Mod. DC
Flange in aluminium
DIMENSIONS (mm)
Mod.
Ø
B
H+
DC-31-12-16
12-16
12,5
38
400
DC-31-20
20
12,5
38
400
DC-31-25
25
13
39,5
400
DC-31-32
32
14,5
44,5
600
DC-31-40
40
14,5
45,5
600
DC-31-50
50
14,5
45,5
600
DC-31-63
63
14,5
50
600
DC-31-80
80
16,5
56
800
DC-31-100
100
19,5
66,5
800
Supplied with:
1
x flange
1
x centering pin
4
x screws
+ = add the stroke
