Compact and Short-Stroke Cylinders 2 NORTH AMERICAN CYLINDER & ACTUATOR CATALOG > Release 8.5
COMPACT AND SHORT-STROKE CYLINDERS
159
CODING EXAMPLE
STANDARD STROKES FOR DOUBLE-ACTING CYLINDERS SERIES 27
27 M 2 A 20 A 0050
27 SERIES
M VERSION
M = rear end block upper round port for ø 20-25-32-40
T = rear end block rear round port for ø 20-25-32-40
U = rear end block upper round port for ø 20-25-32-40-50-63
2 OPERATION
2 = double-acting
A MATERIALS
A = rolled stainless steel rod stainless steel tube
20 BORE
20 = 20 mm
25 = 25 mm
32 = 32 mm
40 = 40 mm
50 = 50 mm
63 = 63 mm
A TYPE OF DESIGN
A = standard
0050 STROKE
(see table)
Mod. 27M and 27T (ø 20 – 40)and Mod. 27U (ø 20 – 63)
Ø 10 25 40 50 80 100 125 160 200 250 300 320 400 500
20 ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■
25 ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■
32 ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■
40 ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■
50 ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■
63 ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■
