Compact and Short-Stroke Cylinders
2
NORTH AMERICAN CYLINDER & ACTUATOR CATALOG
>
Release 8.5
COMPACT AND SHORT-STROKE CYLINDERS
161
Cylinders Series 27 (Ø 20, 25, 32, 40)
DIMENSIONS (mm)
Ø AM B BF BE ØCD
h9
ØD EE EW G G1
KK L L6 ØMM L5 PL
h9
SW VD WF XC+ XC1+ XC2+ SW1
20
14 16 12
M16x1,5 6 21,5 G1\8 12 15,5 8 M8x1,25 7 -
8 13 9 7 3 17 77 62,5 70,8 19
25
16 18 12
M18x1,5 8 26,5 G1\8 14 15,5 8 M10x1,25 9 -
10 17 9 9 3 16,5 78,5 62 69,5 24
32
22 22 15
M22x1,5 8 33,5 G1\8 16 17,5 5,5 M10x1,25 7 20 12 15 9 10 3 23 93 74
86
30
40
23 30 15
M30x1,5 10 41,5 G1\8 20 18 5,5 M12x1,25 5 24 16 15 10 13 3 24 96 78,5 91
38
+ = add the stroke
Cylinders Series 27 (Ø 50, 63)
DIMENSIONS (mm)
Ø AM ØB BG BG1 ØD EE FB G
KK ØMM
h9
PL
RT
RT1 SW TC TF VD WF XC +
50
23 28 12
8
52,5
G1\4 M6 22 M12x1,25 16 13 M10x1
13
13 49 28,5 2
13
97
63
30 35 12 9,5 65,5
G1\4 M8 22 M16x1,5
20 13
M12x1,5 15
17 62 35,5 2
13
99
+ = add the stroke
