Compact and Short-Stroke Cylinders
2
NORTH AMERICAN CYLINDER & ACTUATOR CATALOG
>
Release 8.5
COMPACT AND SHORT-STROKE CYLINDERS
169
Cylinders Series 42
N.B. : the single-acting cylinders, sizes L, L1 and L2 are increased by 25 mm.
DIMENSIONS (mm)
Ø A KK
B B1 B2 B3 B4 C D
d11
D1 D2 D3 E F G SW1 SW2 AM WH L + L1 + L2 + L3 L4 L5 L6 L7 Cushion stroke
32
12
M10x1.25 M30x1.5 8 41.5 28 36 G1\8 30 38 M8x1 42 23.5 10.5 5 10 17 22 26 156 120 94 48 18 15 11 14
17
40
16
M12x1.25 M38x1.5 10 50 30 43 G1\4 38 46 M10x1 50 29 15 5 13 19 24 30 175 135 105 54 22 19 13 16
24
50
20
M16x1.5 M45x1.5 10 58.5 32 54 G1\4 40 57 M12x1.5 60 28.5 14.5 4.5 17 24 32 37 193 143 106 69 25 22 15 18
22
63
20
M16x1.5 M45x1.5 10 70.5 46.5 66 G3\8 45 70 M14x1.5 60 35 15 7 17 24 32 37 208 158 121 69 25 22 15 18
27
+ = add the stroke
Cylinders Series 42
Through rod.
N.B. : the single-acting cylinders, sizes L, L1 and L2 are increased by 25 mm.
DIMENSIONS (mm)
Ø A KK
B B1 B2 B3 B4 C D D1 D2 D3 E F G SW1 AM SW2 WH + L ++ L1 + L2 + L3+ L4 L5 Cushion stroke
32
12
M10x1.25 M30x1.5 8 41.5 28 36 G1\8 30 38 M8x1 42 23.5 10.5 5 10 22
26 190 145 119 48 18 15
17
40
16
M12x1.25 M38x1.5 10 50 30 43 G1\4 38 46 M10x1 50 29 15 5 13 24
30 213 160 130 54 22 19
24
50
20
M16x1.5 M45x1.5 10 58.5 32 54 G1\4 45 57 M12x1.5 60 28.5 14.5 4.5 17 32
37 244 168 131 69 25 22
22
63
20
M16x1.5 M45x1.5 10 70.5 46.5 66 G3\8 45 70 M14x1.5 60 35 15 7 17 32
37 259 158 121 69 25 22
22
+ = add the stroke
++ = add the stroke 2 times
