The company reserves the right to vary models and dimensions without notice.
These products are designed for industrial applications and are not suitable for sale to the general public.
Compact and Short-Stroke Cylinders
2
NORTH AMERICAN CYLINDER & ACTUATOR CATALOG
>
Release 8.5
COMPACT AND SHORT-STROKE CYLINDERS
165
Self aligning rod Mod. GK
Material: zinc-plated steel
DIMENSIONS (mm)
Mod.
Ø
KK
L
L1 L3
L4
Ø A Ø D H I
SW SW1
SW2
B1 AX Z E
GK-20
20
M8x1,25
57
26 21
5
8
12,5 19 17
11
7
13
4
16
4
2
GK-25-32
25-32
M10x1,25
71,5 35 20 7,5
14
22
32 30
19
12
17
5
22
4
2
GK-40
40
M12x1,25
75,5 35 24 7,5
14
22
32 30
19
12
19
6
22
4
2
GK-50-63
50-63
M16x1,5
104
53 32
10
22
32
45 41
27
20
24
8
30
3
2
Female Alignment Coupling Mod. GKF
Material: zinc-plated steel
DIMENSIONS (mm)
Mod.
Ø
KK
A
B
R
TF
L
L1
I
Ø D Ø D1
Ø D2
SW E
GKF-20
20
M8x1,25
30
35
20
25
22,5
10
-
14
5,5
-
13
1,5
GKF-25-32
25-32
M10x1,25
37
60
23
36
22,5
15
6,8
18
11
6,6
15
2
GKF-40
40
M12x1,25
56
60
38
42
22,5
15
9
20
15
9
15
2,5
GKF-50-63
50-63
M16x1,5
80
80
58
58
26,5
15
10,5
25
18
11
22
2,5
