Foot mount Mod. B
Material: zinc-plated steel
Supplied with:
1
x foot
1
x front end cap nut mod. V
DIMENSIONS (mm)
Mod.
Ø
ØAB
AO
AT
AU
NH
SA+
TR
US
XA+
XS
B-27-20
20
5,5
6
3
13
20
79
32
42
83
27
B-27-25
25
6,6
8
3
12,5
22
78
38
49
82
26
B-27-32
32
6,6
8
4
16
25
95
40
54
102
35
B-27-40
40
7
7
4
16
28
99
52
66
107
36
+ = add the stroke
Foot mount Mod. B
Material: zinc-plated steel
Supplied with:
2
x feet
4
x screws
DIMENSIONS (mm)
Mod.
Ø
ØAB
AO
AT
AU
NH
SA+
TR
US
XA+
XS
B-27-50
50
9
10
4
17
40
118
36
52
114
26
B-27-63
63
9
10
5
19
47
124
45
61
118
27
+ = add the stroke
Threaded trunnion pin Mod. T
Material: stainless steel
Supplied with:
2
x pins
DIMENSIONS (mm)
Mod.
Ø
SWSW
ØTD
h9
TL
UT
XG
XJ+
T-27-50
50
6
12
9,5
68
26
84
T-27-63
63
6
14
11
84
26
86
+ = add the stroke
