Compact and Short-Stroke Cylinders 2 NORTH AMERICAN CYLINDER & ACTUATOR CATALOG > Release 8.5
COMPACT AND SHORT-STROKE CYLINDERS
167
CODING EXAMPLE
STANDARD STROKES FOR DOUBLE-ACTING CYLINDERS SERIES 42
42 M 2 N 050 A 0200
42 SERIES
M VERSION
M= standard magnetic
2 OPERATION
1 = single-acting (front spring)
2 = double-acting (front and rear cushions)
3 = double-acting (no cushion)
4 = double-acting (rear cushions)
5 = double-acting (front cushion)
6 = double-acting (through-rod with front and rear cushions)
7 = single-acting (through-rod)
N MATERIALS
N = rod stainless steel AISI 420B - tube stainless steel AISI 304 - NBR seals
050 BORE
032 = 32 mm
040 = 40 mm
050 = 50 mm
063 = 63 mm
A TYPE OF DESIGN
A = standard (threaded nose mount with lock nut V+ lock for nut for rod U)
0200 STROKE
(see table)
✖ = Double acting
■ = Single acting
Ø 25 50 75 80 100 125 150 160 200 250 300 320 400 500
32 ✖ ■ ✖ ■ ✖ ■ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖
40 ✖ ■ ✖ ■ ✖ ■ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖
50 ✖ ■ ✖ ■ ✖ ■ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖
63 ✖ ■ ✖ ■ ✖ ■ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖
