Compact and Short-Stroke Cylinders
2
NORTH AMERICAN CYLINDER & ACTUATOR CATALOG
>
Release 8.5
COMPACT AND SHORT-STROKE CYLINDERS
163
Rear trunnion bracket Mod. I (Ø 20, 25, 32, 40)
Material: zinc-plated steel
Supplied with:
1
x female hinge
1
x pin
2
x C-clips
DIMENSIONS (mm)
Mod.
Ø
G
G1
G2
G3
C
XC+
ØAB
US
NH
ØCD
EW
I-27-20
20
15
30
8
18,5
1,5
77
5,5
15
20
6
12
I-27-25
25
15
33
9
20
2
78,5
6,6
18
22
8
14
I-27-32
32
15
35
10
20
2
93
6,6
20,5
25
8
16
I-27-40
40
20
42
11
25
3
96
7
26
28
10
20
+ = add the stroke
Rear trunnion bracket Mod. I
Material: zinc-plated steel
Supplied with:
2
x pins
2
x feet
DIMENSIONS (mm)
Mod.
Ø
G
G1
C
XJ+
XG
ØAB
K1
K1
K2
K3
NH
UT
I-27-50
50
30
54
4
84
26
9
9
30,5
9
15
40
68
I-27-63
63
40
64
5
86
26
9
9
40,5
9
17,5
47
84
+ = add the stroke
Rod fork end Mod. G
Material: zinc-plated steel
ISO 8140
DIMENSIONS (mm)
Mod.
Ø
ØCK
LE
CM
CL
ER
CE
KK
B
ØB1
G-20
20
8
16
8
16
10
32
M8x1,25
22
14
G-25-32
25-32
10
20
10
20
12
40
M10X1,25
26
18
G-40
40-50
12
24
12
24
14
48
M12X1,25
32
20
G-50-63
63
16
32
16
32
19
64
M16X1,5
40
26
