RODLESS AND GUIDED/TWIN-BORE CYLINDERS
Rodless and Guided/Twin-Bore Cylinders
4
NORTH AMERICAN CYLINDER & ACTUATOR CATALOG > Release 8.5
244
CODING EXAMPLE
STANDARD STROKES FOR TWIN CYLINDERS SERIES QX
QX T 2 A 020 A 050
QX SERIES
T VERSION
T = sintered bronze bushings
B = linear ball bearings
2 OPERATION
2 = double-acting (1 flange) radial / axial pressure supply
3 = double-acting through-rod (double-flange), radial pressure supply
A MATERIALS
A = anodized Aluminium body, rolled stainless steel 303 piston rod
020 BORE
010 = 10 mm
016 = 16 mm
020 = 20 mm
025 = 25 mm
032 = 32 mm
A TYPE OF DESIGN
A = standard
050 STROKE
see table
■ = Double-acting
Ø 10 20 30 40 50 75 100
10 ■ ■ ■ ■ ■ ■
16 ■ ■ ■ ■ ■ ■ ■
20 ■ ■ ■ ■ ■ ■ ■
25 ■ ■ ■ ■ ■ ■ ■
32 ■ ■ ■ ■ ■ ■ ■
