Rodless and Guided/Twin-Bore Cylinders
4
NORTH AMERICAN CYLINDER & ACTUATOR CATALOG
>
Release 8.5
RODLESS AND GUIDED/TWIN-BORE CYLINDERS
249
DIMENSIONS (mm)
Stroke (mm)
Ø 10
Ø 16
Ø 20
Ø 25
Ø 32
A
42
58
62
76
94
B
16
21
25
30
37
C
40
56
60
71
92
E
13
19
22
27
35
F
33
42
50
60
75
G
4
5
6
6
8
I
3,5
2,5
4,5
4,5
4
M
8
10
12
12
16
Q
9
11
16
16
16
R
13
13
18
18
18
L1+
48
57,5
67,5
70,5
80,5
L2+
59,5
70
84
87
100,5
L3
32,1
34
39,5
44,0
46,5
L4
8,5
8,5
9
8,5
12
L5
16
20
25
30
30
L6
10
18
25
30
30
40
L6
20
28
25
30
30
40
L6
30
38
35
40
40
50
L6
40
48
35
40
40
50
L6
50
58
35
40
40
50
L6
75
83
45
60
60
70
L6
100
-
55
60
60
70
L7
13
13
20
20
20
L8
16
30
30
30
30
L9
10
22
25
30
30
40
L9
20
32
25
30
30
40
L9
30
42
35
40
40
50
L9
40
52
35
40
40
50
L9
50
62
35
40
40
50
L9
75
87
45
60
60
70
L9
100
-
55
60
60
70
L10
20,5
29
31
38
47
L11
31
52
57,2
71,5
47
H2
3,5
4,5
5,5
6,5
6,5
H3
2,5
4,0
4,0
4,0
4,0
H4
4,0
5,0
4,5
5,0
7,5
H5
6,5
6,0
6,0
6,0
7,5
H6
8,0
6,0
8,0
8,0
8,0
H7
3,0
3,0
4,0
4,0
4,0
H8
6,3
-
-
-
-
H10
6,5
10,5
10,5
15
8,5
H11
8
16,5
20,2
21,5
28,5
H12
4
10,5
8,00
8,5
8,5
H13
8
-
9,0
13,0
20,0
H14
8
5,5
12,5
15,0
18,5
D1
M4
M5
M6
M8
M8
D2
6
7,5
9,5
10,5
10,5
D3
2,5
2,5
4
4
4
D4
M3
M3
M4
M5
M5
D5
M3
M4
M4
M5
M5
D6
M3
M3
M4
M4
M4
D7
2,5
2,5
4,0
4,0
4,0
D8
6,0
-
-
-
-
D9
3,5
-
-
-
-
D10
M4
M5
M5
M6
M6
NN
6
8
10
12
16
EE
M5
M5
M5
M5
G1/8
J
4,3
-
-
-
-
K
7
7
8
8
10
P
20
25
29
35
45
+ = add the stroke
Dimensions for Series QX with single flange
