GRIPPING FORCE CHARACTERISTICS
F = Gripping Force
L = Gripping point length
CODING EXAMPLE
CGL -
20 40
CGL
SERIES
20
SIZES
10
= ø 10 mm
16
= ø 16 mm
20
= ø 20 mm
25
= ø 25 mm
32
= ø 32 mm
40
STROKE (see dimension tables for optional strokes available)
