ISO / VDMA CYLINDERS
ISO / VDMA Cylinders
1
22
Centre trunnion Mod. F
Material: zinc-plated steel
DIMENSIONS (mm)
Mod.
Ø
XV1
XV2
XV3
TM
TK
TD
TL
UW
R
F-32
32
62
73
84
50
20
12
12
60
0,1
F-40
40
71,5
82,5
93,5
63
25
16
16
68
0,15
F-50
50
79
90
101
75
25
16
16
80
0,15
F-63
63
88,5
97,5
106,5
90
30
20
20
95
0,15
F-80
80
97
110
123
110
30
20
20
120
0,15
F-100
100
104,5
120
135,5
132
30
25
25
135
0,2
F-125
125
123
145
167
160
30
25
25
160
0,2
Supplied with:
1
x intermediate trunnion
8
x clamping pins
8
x set screws
+ = add the stroke
Accessory combination Mod. I (combination of models C + L + S)
Material: Aluminium
DIMENSIONS (mm)
Mod.
Ø
ØCD
L
FL
XD+
TG
E
I
M
ØN
torque force
I-41-32
32
10
12
22
142
32,5
45
10
22
6,5
6
Nm
I-41-40
40
12
15
25
160
38
52
10
25
6,5
6
Nm
I-41-50
50
12
15
27
170
46,5
63
12
27
9
13
Nm
I-41-63
63
16
20
32
190
56,5
73
12
32
9
13
Nm
I-41-80
80
16
24
36
210
72
95
12
36
11
19
Nm
I-41-100
100
20
29
41
230
89
115
12
41
11
22
Nm
I-41-125
125
25
30
50
275
110
135
20
50
13
26
Nm
+ = add the stroke
