ISO / VDMA CYLINDERS
ISO / VDMA Cylinders
1
25
Accessory for mounting valves on the cylinder
The mounting sub-base Mod. PCV enables the valve to be mounted directly on the cylinder using Stud Manifold
bolts Mod. 1635 or flow controllers, Mod. SCU. The stud bolts used to attach the valve outlet ports to the PCV
mounting plate are model number 1631-01-**(thread size of valve). The other end of the plate has a threaded
port to connect fittings to the rear end-cap port.
DIMENSIONS (mm)
Mod.
Ø
A
B
C
R
S
d*
Valve Model To Use
(
Standard valves with end cap turned 180°)
PCV-32
32
G1/8
185
131,5
G1/8
16
G1/8 458-015-22-S19
PCV-40-50
40
G1/8
188,5
140,5
G1/4
16
G1/4 458-015-22-S19
PCV-40-50
50
G1/8
188,5
150
G1/4
16
G1/4 458-015-22-S19
PCV-63-80
63
G1/4
215
167
G1/4
16
G3/8 454-015-22-S07
PCV-63-80
80
G1/4
215
185
G1/4
16
G3/8 454-015-22-S07
d* = mounting on the
cylinder using Mod. 1635 or
Mod. SCU.
Note: the minimum possible
stroke is 100mm.
Rod fork end Mod. G
ISO 8140
Material: zinc-plated steel
DIMENSIONS (mm)
Mod.
Ø
ØCK
LE
CM
CL
ER
CE
KK
B
B1
G-25-32
32
10
20
10
20
12
40
M10X1,25
26
18
G-40
40
12
24
12
24
14
48
M12X1,25
32
20
G-50-63
50-63
16
32
16
32
19
64
M16X1,5
40
26
G-80-100
80-100
20
40
20
40
25
80
M20X1,5
48
34
G-41-125
125
30
55
30
55
38
110
M27X2
74
48
