ISO / VDMA CYLINDERS
ISO / VDMA Cylinders
1
27
Coupling piece Mod. GKF
Material: Zinc-Aluminum alloy and
zinc-plated steel.
DIMENSIONS (mm)
Mod.
Ø
KK
A
B
R TF
L
L1
I
Ø D Ø D1
Ø D2
SW E
GKF-25-32
32
M10x1,25
37
60
23
36
22,5
15
6,8
18
11
6,6
15
2
GKF-40
40
M12x1,25
56
60
38
42
22,5
15
9
20
15
9
15
2,5
GKF-50-63
50-63
M16x1,5
80
80
58
58
26,5
15
10,5
25
18
11
22
2,5
GKF-80-100
80-100
M20x1,5
90
90
65
65
32,5
20
13
30,5
20
14
27
2,5
GKF-125
125
M27x2
90
90
65
65
35,5
20
13
40
20
14
36
4
