NORTH AMERICAN CYLINDER & ACTUATOR CATALOG
>
Release 8.5
The company reserves the right to vary models and dimensions without notice.
These products are designed for industrial applications and are not suitable for sale to the general public.
ISO / VDMA CYLINDERS
ISO / VDMA Cylinders
1
23
90
° male trunnion Mod. ZC
CETOP RP 107P
Material: aluminium
DIMENSIONS (mm)
Mod.
Ø EB ØCK HB XD+
TE
UL
EA GL
L5
RA EM UR PH BT
BR
ZC-32
32
11
10
6,6
142
38
51
10
21
1,6
18
26
31
32
8
10
ZC-40
40
11
12
6,6
160
41
54
15
24
1,6
22
28
35
36
10
11
ZC-50
50
15
12
9
170
50
65
16
33
1,6
30
32
45
45
12
13
ZC-63
63
15
16
9
190
52
67
16
37
1,6
35
40
50
50
14
15
ZC-80
80
18
16
11
210
66
86
20
47
2,5
40
50
60
63
14
15
ZC-100
100
18
20
11
230
76
96
20
55
2,5
50
60
70
71
17
19
ZC-125
125
20
25
14
275
94
124
30
70
3,2
60
70
90
90
20
22,5
Supplied with:
1
x male trunnion
+ = add the stroke
Rear trunnion ball-joint Mod. R*
Material: aluminium
*
not according to standard
DIMENSIONS (mm)
Mod.
Ø
ØCX
L
DL
XN+
MS
E
EX
EP
Z
torque force
R-41-32
32
10
12
22
142
16
45
14
10,5
4
6
Nm
R-41-40
40
12
15
25
160
20
52
16
12
4
6
Nm
R-41-50
50
12
15
27
170
20
63
16
12
4
13
Nm
R-41-63
63
16
20
32
190
24
73
21
15
4
13
Nm
R-41-80
80
16
24
36
210
24
95
21
15
4
19
Nm
R-41-100
100
20
29
41
230
30
115
25
18
4
22
Nm
R-41-125
125
30
30
50
275
40
140
37
25
4
26
Nm
Supplied with:
1
x trunnion ball joint
4
x screws
+ = add the stroke
EXPRESS DELIVERY AVAILABLE
