ISO / VDMA CYLINDERS
ISO / VDMA Cylinders
1
30
CYLINDER IN THRUST
DRAWING NOTES:
1.
Precision pressure regulator or electro-pneumatic regulator
2.
Low friction cylinder
3.
Force direction
4.
Band
CYLINDER IN TRACTION
Note: in order to reach the highest performance, it is
recommended to connect precision pressure regulator or an
electro-pneumatic regulator with the low friction cylinder as
shown in the drawing.
Low friction cylinders Series 61 - APPLICATION EXAMPLES
1
= rod seal
2
= c-clip
3
= metal scraper
Low temperature cylinders Series 60 - DETAIL
Rod scraper included in all low-temperature cylinders
