ISO / VDMA CYLINDERS
ISO / VDMA Cylinders
1
33
ø Rod extension [X]
(
mm)
Holding force
[
static load] (N)
20
+50
300
25
+48
400
32
+40
650
40
+43
1100
50
+57
1600
63
+57
2500
80
+80
4000
100
+80
6300
125
+125
8800
Cylinders Series 61 - tandem version
DIMENSIONS (mm)
Ø
EE
L2+
L3+
32
G1/8
172,5
197,5
40
G1/4
191,5
221,5
50
G1/4
188
225
63
G3/8
204
241
80
G3/8
225,5
271,5
100
G1/2
231
282
125
G1/2
264
329
+ = add the stroke
++ = add the stroke two
times
Cylinders Series 61 with rod lock
DIMENSIONS (mm)
Ø ØD ØD1 ØD2 ØD3 A
G H H1
L1 L2 L3 L4 L5 L6 L7 L8 L9+ L10+ M WH Z
32
12 30.5 35 25 32,5
M5 25,5 46,5 58 48 10 8 13 20,5 34 45 94 160 M6
66
M6x20
40
16 35
40 28 38
G1/8 30
53
65 55 10 8 13 22,5 38 50 105 178
M6
73
M6x20
50
20 40
50 35 46,5
G1/8 36
64
82 70 12 15 16 29,5 48 60 106 200
M8
94
M6x20
63
20 45
60 38 56,5
G1/8 40
75
82 70 12 15 16 29,5 49,5 70 121 215
M8
94
M8x30
80
25 45
80 48 72
G1/8 50
95
110 90 20 18 20 35 61 90 128 254
M10 126 M10x35
100
25 55 100 58 89
G1/8 58 110,5 115 100 15 18 20 39 69 105 138 269 M10 131 M10x35
125
32 60 130 65 110
G1/8 80
150 167 122 45 22 30 51 86,5 140 160 350
M12 190 M12x40
+ = add the stroke
EXPRESS DELIVERY AVAILABLE
