Compact and Short-Stroke Cylinders
2
NORTH AMERICAN CYLINDER & ACTUATOR CATALOG
>
Release 8.5
COMPACT AND SHORT-STROKE CYLINDERS
119
Self aligning rod Mod. GK
Material: zinc-plated steel
DIMENSIONS (mm)
Mod.
Ø
KK
L
L1 L3 L4 Ø A Ø D H I
SW SW1 SW2 B1 AX Z E
GK-20
16
M8x1,25
57
26 21
5
8
12,5 19 17
11
7
13
4
16 4 2
GK-25-32
20-25-32-40
M10x1,25 71,5 35 20 7,5
14
22
32 30
19
12
17
5
22 4 2
GK-40
50-63
M12x1,25 75,5 35 24 7,5
14
22
32 30
19
12
19
6
22 4 2
GK-50-63
80
M16x1,5
104 53 32 10
22
32
45 41
27
20
24
8
30 3 2
GK-80-100
100
M20x1,5
119 53 40 10
22
32
45 41
27
20
30
10 37 3 2
Coupling piece Mod. GKF
Material: zinc-plated steel
DIMENSIONS (mm)
Mod.
Ø
KK
A
B
R TF
L
L1
I
Ø D Ø D1
Ø D2
SW E
GKF-20
16
M8x1,25
30
35
20
25
22,5
10
-
14
5,5
-
13
1,5
GKF-25-32
20-25-32-40
M10x1,25
37
60
23
36
22,5
15
6,8
18
11
6,6
15
2
GKF-40
50-63
M12x1,25
56
60
38
42
22,5
15
9
20
15
9
15
2,5
GKF-50-63
80
M16x1,5
80
80
58
58
26,5
15
10,5
25
18
11
22
2,5
GKF-80-100
100
M20x1,5
90
90
65
65
32,5
20
13
30,5
20
14
27
2,5
