Compact and Short-Stroke Cylinders
2
NORTH AMERICAN CYLINDER & ACTUATOR CATALOG
>
Release 8.5
COMPACT AND SHORT-STROKE CYLINDERS
173
Self aligning rod Mod. GK
Material: zinc plated steel
DIMENSIONS (mm)
Mod.
Ø
KK
L
L1 L3
L4
Ø A Ø D H I
SW SW1
SW2
B1 AX Z E
GK-25-32
32
M10x1,25
71,5
35 20 7,5
14
22
32 30
19
12
17
5
22
4
2
GK-40
40
M12x1,25
75,5
35 24 7,5
14
22
32 30
19
12
19
6
22
4
2
GK-50-63
50-63
M16x1,5
104
53 32
10
22
32
45 41
27
20
24
8
30
3
2
Female Alignment Coupling Mod. GKF
Material: zinc plated steel
DIMENSIONS (mm)
Mod.
Ø
KK
A
B
R
TF
L
L1
I
ØD ØD1
ØD2
SW E
GKF-25-32
32
M10x1,25
37
60
23
36
22,5
15
6,8
18
11
6,6
15
2
GKF-40
40
M12x1,25
56
60
38
42
22,5
15
9
20
15
9
15
2,5
GKF-50-63
50-63
M16x1,5
80
80
58
58
26,5
15
10,5
25
18
11
22
2,5
