Stainless Steel Cylinders
3
NORTH AMERICAN CYLINDER & ACTUATOR CATALOG > Release 8.5
STAINLESS STELL CYLINDERS
181
CODING EXAMPLE
STANDARD STROKES FOR MINICYLINDERS SERIES 94 AND 95
94 N 2 A 16 A 100
94 SERIES
94 = magnetic
95 = magnetic, cushioned
N VERSION
N = standard
2 OPERATION
1 = single-acting (front spring)
2 = double-acting
3 = double-acting (through-rod)
A MATERIALS
A = stainless steel, seals in NBR (Buna-N)
V = stainless steel, all seals in FKM , (VITON)
16 BORE (ø):
16 = 16 mm
20 = 20 mm
25 = 25 mm
A TYPE OF DESIGN
A = standard (locking ring for end cap V + lock nut for rod U)
100 STROKE
(see table)
= standard
V = rod seals in FKM , (VITON)
■ = double-acting
✖ = single-acting
Ø 10 25 40 50 80 100 125 160 200 250 300 320 400 500
94 16 ■ ✖ ■ ✖ ■ ✖ ■ ✖ ■ ■ ■ ■ ■
94 20 ■ ✖ ■ ✖ ■ ✖ ■ ✖ ■ ■ ■ ■ ■ ■ ■
94 25 ■ ✖ ■ ✖ ■ ✖ ■ ✖ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■
95 25 ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■
