COMPACT AND SHORT-STROKE CYLINDERS
Compact and Short-Stroke Cylinders
2
NORTH AMERICAN CYLINDER & ACTUATOR CATALOG
>
Release 8.5
172
Piston rod lock Mod. U
DIMENSIONS (mm)
Mod.
Ø
D
m
SW
U-25-32
32
M10X1,25
6
17
U-40
40
M12X1,25
7
19
U-50-63
50-63
M16X1,5
8
24
Swivel ball joint Mod. GA
Material: zinc-plated steel
ISO 8139
DIMENSIONS (mm)
Mod.
Ø
ØCN
U
EN
ER
AX
CE
KK
T
Z
SW
GA-32
32
10
10,5
14
14
20
43
M10X1,25
15
6,5
17
GA-40
40
12
12
16
16
22
50
M12X1,25
17,5
6,5
19
GA-50-63
50-63
16
15
21
21
28
64
M16X1,5
22
7,5
22
Piston rod socket joint Mod. GY
Material: Zinc-Aluminum alloy and
zinc-plated steel
DIMENSIONS (mm)
Mod.
Ø
KK
L
CE L2
AX SW SW1
L1
L3
ØT
ØD E ØB ØC Z
GY-32
32
M10x1,25
74
35
6,5
18
17
11
19,5
15
15
19
10
14
28
15
GY-40
40
M12x1,25
84
40
6,5
20
19
17
22
17
17,5
22
12
19
32
15
GY-50-63
50-63
M16x1,5
112
50
8
27
22
19
27,5
23
22
27
16
22
40
11
