COMPACT AND SHORT-STROKE CYLINDERS
Compact and Short-Stroke Cylinders
2
NORTH AMERICAN CYLINDER & ACTUATOR CATALOG
>
Release 8.5
170
Foot mount Mod. P
Material: zinc-plated steel.
DIMENSIONS (mm)
Mod.
Ø L1
SA +
XA +
A
AB AO AH C G G1
TR TR1
TR2
TR3
H
P-42-32
32
46
142
144
24
7
11
32
4
66
53
52
28
32
52
18
P-42-40
40
53
161
163
28
9
15
36
5
80
61
60
30
36
60
21
P-42-50
50
63
170
175
32
9
15
45
6
90
75
70
40
45
70
25
P-42-63
63
63
185
190
32
9
10
50
6
96
85
76
50
50
76
25
Supplied with:
1
x nut
2
x single feet
+ = add the stroke
Trunnion Mod. I
Material: zinc-plated steel.
DIMENSIONS (mm)
Mod.
Ø L1 +
L2
L3 +
C C1
C2
C3
D1
D2
E1
F
SW1
G
G1
G2
I-42-32
32
109,5
36,5
105,5
40
24
46,1
20
7
10
4
35
13
38,1
50,1
58,1
I-42-40
40
120
45
117
50
30
56,1
28
9
12
5
40
17
46,1
60,1
70,1
I-42-50
50
128,5
51,5
124,5
54
34
69,1
36
9
14
6
45
19
57,1
74,1
86,1
I-42-63
63
143
52
142
65
35
82,1
42
9
16
6
50
19
70,1
88,1
100,1
+ = add the stroke
