Stainless Steel Cylinders
3
NORTH AMERICAN CYLINDER & ACTUATOR CATALOG > Release 8.5
STAINLESS STELL CYLINDERS
187
CODING EXAMPLE
STANDARD STROKES FOR CYLINDER SERIES 90
90 M 2 A 050 A 0200
90 SERIES
M VERSION
M = standard, magnetic
2 OPERATION
1 = single-acting (front spring)
2 = double-acting (front and rear cush.)
6 = double-acting (through-rod with front and rear cushions)
A MATERIALS
A = stainless steel AISI 316 (SS 2343), seals in NBR, (Buna-N)
V = stainless steel AISI 316 (SS 2343), all seals in FKM, (VITON)
050 BORE (ø):
032 = 32 mm
040 = 40 mm
050 = 50 mm
063 = 63 mm
080 = 80 mm
100 = 100 mm
125 = 125 mm
A TYPE OF DESIGN
A = standard
0200 STROKE
see table
= standard
V = rod seals in FKM, (VITON)
✖ = Double-acting
● = Single-acting
Ø 25 50 75 80 100 125 150 160 200 250 300 320 400 500
32 ✖● ✖● ✖● ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖
40 ✖● ✖● ✖● ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖
50 ✖● ✖● ✖● ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖
63 ✖● ✖● ✖● ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖
80 ✖● ✖● ✖● ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖
100 ✖● ✖● ✖● ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖
125 ✖● ✖● ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖
