ISO / VDMA CYLINDERS
ISO / VDMA Cylinders
1
36
Rear male trunnion Mod. L
Material: Aluminium
DIMENSIONS (mm)
Mod.
Ø
CD
L
FL
XD+
MR
E
EW
torque force
L-41-32
32
10
12
22
142
9
45
26
6
Nm
L-41-40
40
12
15
25
160
13
52
28
6
Nm
L-41-50
50
12
15
27
170
13
63
32
13
Nm
L-41-63
63
16
20
32
190
15
73
40
13
Nm
L-41-80
80
16
24
36
210
15
95
50
19
Nm
L-41-100
100
20
29
41
230
18
115
60
22
Nm
L-41-125
125
25
30
50
275
25
135
70
26
Nm
Supplied with:
1
x male trunnion
4
x screws
+ = add the stroke
Centre trunnion Mod. F
Material: zinc-plated steel
DIMENSIONS (mm)
Mod.
Ø
XV1
XV2
XV3
TM
TK
TD
TL
UW
R
F-61-32
32
61
73
85
50
18
12
12
65
0,1
F-61-40
40
69
82,5
96
63
20
16
16
75
0,15
F-61-50
50
76,5
90
103,5
75
20
16
16
91
0,15
F-61-63
63
86
97,5
109
90
25
20
20
94
0,15
F-61-80
80
94,5
110
125,5
110
25
20
20
130
0,15
F-61-100
100
104,5
120
135,5
132
30
25
25
145
0,2
F-61-125
125
123
145
167
160
30
25
25
155
0,2
Supplied with:
1
x centre trunnion
8
x set screws
8
x clamping pins
+ = add the stroke
