Trunnion ball-joint Mod. R*
Material: Aluminium
*
not according to standard
DIMENSIONS (mm)
Mod.
Ø
CX
L
DL
XN+
MS
E
EX
EP
Z
torque force
R-41-32
32
10
12
22
142
16
45
14
10,5
4
6
Nm
R-41-40
40
12
15
25
160
20
52
16
12
4
6
Nm
R-41-50
50
12
15
27
170
20
63
16
12
4
13
Nm
R-41-63
63
16
20
32
190
24
73
21
15
4
13
Nm
R-41-80
80
16
24
36
210
24
95
21
15
4
19
Nm
R-41-100
100
20
29
41
230
30
115
25
18
4
22
Nm
R-41-125
125
30
30
50
275
40
140
37
25
4
26
Nm
Supplied with:
1
x trunnion ball joint
4
x screws
+ = add the stroke
Counter bracket for centre trunnion Mod. BF
Material: Aluminium
DIMENSIONS (mm)
Mod.
Ø
CR
NH
C
B3
TH
UL
FK
FN
B1
B2
HB
BF-32
32
12
15
7,5
3
32
46
15
30
6,8
11
6,6
BF-40-50
40 - 50
16
18
9
3
36
55
18
36
9
15
9
BF-63-80
63 - 80
20
20
10
3
42
65
20
40
11
18
11
BF-100-125
100 - 125
25
25
12,5
3,5
50
75
25
50
13
20
14
Supplied with:
2
x supports
