Tandem cylinders Mod. 32F2A/32M2A...N2
DIMENSIONS (mm)
Ø A AF BG ØD ØD2 ØD3 ØD4 E EE E1 H H1 H2 KF
KK LA PL RT SW1 T1 T2 TG
25
16 11 16,5 10 -
-
9 40,7
M5
-
76 81,7 44
M6 M8X1,25 5 7 M5 8
-
2,5 26
40
19 13 21,5 12 35 29
9
57
G1/8 -
86 93 48,2
M8 M10X1,25 5 7,6 M6 10 2 2,5 38
63
22 16 18,5 16 45 39 12 79,6
G1/8 12’5 93 101
-
M10 M12X1,25 6 7,6 M8 13 2 3 56,5
100
28 20 20 25 55 49 12 115,6
G1/8 25 121 130,7 -
M12 M16X1,5 6 8 M10 22 2 3 89
+ = add the stroke
++ = add the stroke two times
1
= Groove for sensor
2
= Positive stroke
3
= Negative stroke
